7HP Gasoline Engine
- Model: 170F
- Power: 7HP
- Product description: ♦ OHV leads to the lower fuel consumption. ♦ Oil alert automatically shut off the engine.
Product introduction
| 4 stroke Air cooled gasoline engine | ||
| Model | 170F | |
| Gasoline Engine | Low oil protector | yes |
| Rated output(HP) | 7HP | |
| Bore*stroke(mm*mm) | 70*54 | |
| Fuel tank capacity(L) | 3.6 | |
| Lube oil capacity(L) | 0.6 | |
| Governor system | All-speed type,Mechanical Governor | |
| Gasoline engine type | air cooled,4 stroke,OHV 25.Inclined single cylinder | |
| Compression ratio | 8.5:1 | |
| Displacement (cc) | 207 | |
| Fuel Consumption(g/Kwh) | 360 | |
| Spark Plug | F6TC | |
| Lube oil system | Splash type | |
| Ignition system | Non-contact transistorize ignition(TCL) | |
|
Other Information |
N.W/G.W(KG) | 17.5/19 |
| Specification:(mm) | 415*350*385 | |
| packing: | CARTON | |
| Quantity for 20ft:(set) | 540SETS | |
| Warranty time: | One year | |
